Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 4 QUICK START Page 4.2
4.1.2 STEP ONE CONFIGURE A LAYER TWO INTERFACE
1. Select Layer 2 Interface
2. Next you need to add an ‘ATM’ interface so select ‘ Add’
You will then be presented with the following page
ATM PVC Configuration
This screen allows you to configure an ATM PVC identifier (VPI and VCI), select DSL latency,
select a service category. Otherwise choose an existing interface by selecting the checkbox to
enable it.
Configuration
Set to
Option
VPI [0 – 255]
0
Usual default for UK
VCI [32-65535]
38
Usual default for UK (This value will be used by the router
to identify this path. This path will appear later as an
option)
Select DSL Latency
Path0
The 6401 only has a single DSL path - select path 0
Select DSL Link
Type
PPPoA
Select the service your ISP has provided, most common in
the UK is PPPoA
Select Connection
Mode
VC Mux
Select the mode of operation provided by your ISP, the
most common is VC Mux in the UK
Service Category
UBR
without PCR
Unless a specific service has been selected use UBR
without PCR
Select IP QoS Scheduler Algorithm
Strict Priority
Unless the router is on a network with QoS this option can
be left as defaulted
Select
APPLY / SAVE
4.1.3 STEP 2 – SELECT WAN SERVICE
1. Select on WAN Service
2. Click Add
3. The following page is displayed
WAN Service Interface Configuration
Select a layer 2 interface for this service
Note: For ATM interface, the descriptor string is (portId_vpi_vci)
For PTM interface, the descriptor string is (portId_high_low)
Where portId=0 --> DSL Latency PATH0
portId=1 --> DSL Latency PATH1
portId=4 --> DSL Latency PATH0&1
low =0 --> Low PTM Priority not set
low =1 --> Low PTM Priority set
high =0 --> High PTM Priority not set
high =1 --> High PTM Priority set
Atm0/0_0_38
