Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 4 QUICK START Page 4.3
SELECT THE WAN INTERFACE
Select the interface from the drop down menu. As its likely your going to connect to an ADSL
WAN Service the interface is the likely to be described by the VCI configured earlier (eg 38)
Atm0/0_0_38
If running PPPoA the link type (pppoa) and VPI / VCI will be displayed in the field. This can be
changed to reflect a more meaningful name.
Enter Service Configuration
4. Click Next
You will then see the following options
PPP Username and Password
PPP usually requires that you have a user name and password to establish your connection. In the
boxes below, enter the user name and password provided by your ISP .
Enter the username provided by your ISP
Enter the password supplied by your ISP
Select from drop down menu
Dial on demand (with idle timeout timer
Enable IGMP Multicast Proxy
