2 GETTING STARTED
2.1 CONNECTING A PC TO THE CASE 6401
Use a standard UTP Patch lead to connect a PC to the 6401 via any of the 4 Ethernet ports on the rear
of the 6401. Using a standard browser (i.e. Firefox, Google Chrome, Internet Explorer etc.), enter the
IP address of the router. It’s possible some restrictions may have been configured within the router,
therefore if one port does not allow access then move your PC to one of the other ports until the logon
screen is retrieved.
If it’s not possible to get a response from any of the Ethernet ports, press the ‘reset’ switch on the rear
of the 6401 router in for 10 seconds which returns the 6401 to its default configuration.
The default IP Address of the Case 6401 router is 192.168.1.1
There are three operational modes, each with its own user ‘Logon’ name and password as shown
below. The menu options available will vary depending on the logon status of the user
