EXAMPLE 2 – TRAFFIC ON ETH 0 USING 802.1Q
Parameter
Value
Meaning
Traffic Class Name
Eth-0
Name of the Traffic Class Rule
Rule Order:
Last
Last rule to be processed
Rule Status
Enable
Enable this rule
Specify Classification Criteria
A blank criterion indicates it is not used for classification.
Class Interface:
Eth0
We apply this rule to eth0
Ether Type
8021Q
802.1p Priority Check
1
Drop down selection 0-7
Specify Classification Results
Assign Classification Queue:
Atm0&atm0path&key56&Pre8 (from drop down menu)
Mark Differentiated Service
Code Point (DSCP):
AF23 Low priority higher medium high drop rate
Mark 802.1p priority
6
Select form drop down menu range 0 to 7
Tag VLAN ID [0-4094]:
N/A
Enter VLAN tag ID
Set Rate Control (kbps)
24
Enter bandwidth to assign for this QoS
CLASSIFICATION CRITERA
Class
Name
Order
Class
Intf
Ether
Type
SrcMA
C/MAS
K
Dst
MAC/
Mask
SrcIP/ Prefix
Length
DstIP
Prefix
Length
Proto
Src
Port
Dst
Port
DSCP
Check
802.1P
Check
Eth-0
1
Eth0
8021
Q
1
CLASSIFICATION RESULTS
Queue Key
DSCP Mark
802.1P Mark
VLAN ID tag
Rate Control Kbps
Enable
Remove
56
default
6
24

EXAMPLE 3 WAN - SNMP TRAPS ON WAN
Please note that using the WAN Interface for QoS requires at least one of the Ethernet ports
configured as a Queue (see above)
Parameter
Value
Meaning
Traffic Class Name
SNMP-Trap
Enter a name
Rule Order:
Last
Only option for this configuration
Rule Status
Enable
Enable / Disable
Specify Classification Criteria
A blank criterion indicates it is not used for classification.
Class Interface:
WAN
LAN, WAN, Local, eth1, eth2, eth3,eth4
Ether Type
IP (0x800)
Only option allowed on WAN
Source MAC Address:
Not reqd
Enter Source Device MAC Address
Source IP Address/Mask
Not reqd
Enter Source IP Address
DSCP Check
default
Assign priority
Protocol
TCP
TCP, UDP, ICMP, IGMP
UDP/TCP Source Port
162
Select port number for the application
UDP/TCP Destination Port
162
Select port number for the application
