Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.22
Connection Type:
PPPoE
NAT:
Enabled
Full Cone NAT:
Disabled
Firewall:
Enabled
IGMP Multicast:
Disabled
Quality Of Service:
Enabled
Click "Apply/Save" to have this interface to be effective. Click "Back" to make any modifications.
Having selected ‘Apply / save’ we are taken back to the following Wide Area Service SetUp
overview.
Wide Area Network (WAN) Service Setup
Choose Add, Remove or Edit to configure a WAN service over a selected interface.
Interface
Description
Type
VLAN
8021p
VLANMuxId
IGMP
NAT
Firewall
Remove
Edit
PPPoa0
Case_WAN
PPPoA
N/A
N/A
Disabled
Enabled
Enabled
ppp1
PPPoL2tpAc
PPPoE
N/A
N/A
Disabled
Enabled
Enabled
To Check the L2TP configuration return to the L2TP menu option and now you will see the following
tunnel configured.
L2TP Client Side PPP Connection
Choose Add, Remove to configure a PPP over L2TP WAN Service)
