Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.14
Enter a free form name for this service or
keep the default provided
Enter the name provided by your ISP
Enter the password provided by your ISP
Select from drop down menu
(Auto, PAP, CHAP, MSCHAP)
Default (for explanations please see
end of this section)
Dial on demand with idle timer
Use Static IPv4 Address (If selected field below opens)
Enter your static IPv4 Address
Bridge PPPoE frame between WAN and Local ports
Enable Multicast IGMP Proxy
Select Next to be shown the ‘Routing Default Gateway.
Default gateway interface list can have multiple WAN interfaces served as system default gateways
but only one will be used according to the priority with the first being the higest and the last one the
lowest priority if the WAN interface is connected. Priority order can be changed by removing all and
adding them back in again.
Select Default Gateway Interfaces
Available Routed WAN Interfaces
Note if only one interface has been configured
it will be automatically added to the default
gateway
To Next Page
