Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.3
LAYER 2 CONFIGURATION OPTIONS
On selecting add, a Layer 2 Interface the following page is presented. Here we see the option
to configure 3 different layer 2 interfaces with the page appearing slightly different according
to which of the three options has been selected;
1. Ethernet Over ATM
2. Point to Point Protocol Over ATM
3. IP Over ATM
Parameter
Value
Options
VPI [ 0- 255:]
0
Set according to ISP requirements
VCI 0 [0 – 65535] (UK =38)
38
Set according to ISP requirements
(1-31 is generally reserved)
Select DSL Latency
Path 0
Select a Path0 or Path 1(6401 only has 1 path=0)
Select DSL Link Type (EoA is for PPPoE, IPoE, and Bridge.)
EoA
Select for PPPoE, IPoE or Bridging
PPPoA
PPPoA
Select for PPPoA – if that’s ISP Service
IPoA
Select for IP over ATM
EOA CONFIGURATION OPTIONS
Select Connection Mode
Default Mode / VLAN
VLAN Mux
Single Service over one connection or Multiple
Mux Mode
VLAN Services over one connection.
Encapsulation Mode
VC Mux
Configure in accordance with ISP service.
VC Mux
LLC / SNAP – Bridging
See note at end of this section for explanation
Service Categories see Service Category Table below
PPPoA CONFIGURATION OPTIONS
Select Connection Mode
Encapsulation Mode
VC Mux
Configure in accordance with ISP service.
VC Mux
LLC / SNAP-Routing
See note at end of this section for explanation
Service Categories see Service Category Table below
IPoA CONFIGURATION OPTIONS
Select Connection Mode
Encapsulation Mode
VC Mux
Configure in accordance with ISP service.
VC Mux
LLC / Encapsulation
See note at end of this section for explanation
Service Categories see Service Category Table below
