Case Communications 6401 Rugged ADSL Router Manual – Rev 1.5
SECTION 5 – ADVANCED CONFIGURATION Page 5.26
NAT – Virtual Server Setup Options
A drop down menu shows the interfaces available. These are the interfaces
previously configured under the WAN Interface.
Select a service name from the drop down list.
You can add your own service in this field
The IP Address of the server on the LAN side
The table below provides an example of a Virtual Server Configuration.
NAT – Virtual Server Setup Example – X-Windows
Select an interface from the drop down list
Select a pre-defined name form the drop down list or select ‘custom
service’ and configure your own parameters
Use a free form name and configure your parameters.
The following table can allow mapping of internal to external ports and allows the network manager
to configure whether the protocol should be TCP and UDP, TCP only or UDP only
Having configured your options select ‘Next’ and the following summary display will be shown,
allowing the network manager to view the options configured.
