Destination IP Address Enter the IP Address of the remote service the application is to reach.
E.g. 172.16.20.1/ 16 (255.255.0.0)
Differentiated Services Select from the drop down menu, the options within the DSCP Drop
Code Point (DSCP) Check. down menu are;
Protocol Select from drop down menu – TCP – UDP – ICMP-IGMP (where
IPv6 ICMPv6 is displayed)
Specify Classification Select the ‘Classification Queues’ previously configured under
Results Assign Classify ‘Queue Config. Note they will have been given ‘key’ numbers.
Queue
Mark Differential This is the same drop down menu as shown above and allows
Service Code Point (DSCP) you to mark the traffic with a DSCP value.
Mark 802.1p Priority Provides a layer 2 802.1p priority to unassigned frames. Please refer
to the table previously showing the 802.1p priority levels.
TAG VLAN ID IEEE 802.1Q is the networking standard that supports Virtual LANs
(VLANs) on an Ethernet network. The standard defines a system of
VLAN tagging for Ethernet frames and the accompanying procedures
to be used by bridges and switches in handling such frames. The
standard also contains provisions for a quality of service prioritization
scheme commonly known as IEEE 802.1p and defines the Generic
Attribute Registration Protocol.
802.1Q does not actually encapsulate the original frame. Instead, for
Ethernet frames, it adds a 32-bit field between the source MAC
address and the EtherType/Length fields of the original frame,
