Interface grouping Configuration
To create a new interface group:
1. Enter the Group name and the group name must be unique and select either
(dynamic)
or
(static) below:
2. To automatically add LAN clients to a WAN Interface in the new group add the DHCP vendor ID
string.
By configuring a DHCP vendor ID string any DHCP client request with the specified vendor ID
(DHCP option 60) will be denied an IP address from the local DHCP server.
3.Select interfaces from the available interface list and add it to the grouped interface list using the
arrow buttons to create the required mapping of the ports. Note that these clients may obtain public IP
addresses
4. Click Apply/Save button to make the changes effective immediately
IMPORTANT If a vendor ID is configured for a specific client device, please REBOOT the client
device attached to the modem to allow it to obtain an appropriate IP address.
6401 Rugged Router
Interface grouping Configuration
To create a new interface group:
1. Enter the Group name and the group name must be unique and select either 2. (dynamic) or 3. (static) below:
2. If you like to automatically add LAN clients to a WAN Interface in the new group add the DHCP vendor ID string. By configuring a DHCP vendor
ID string any DHCP client request with the specified vendor ID (DHCP option 60) will be denied an IP address from the local DHCP server.
3.Select interfaces from the available interface list and add it to the grouped interface list using the arrow buttons to create the required mapping of the
ports. Note that these clients may obtain public IP addresses
4. Click Apply/Save button to make the changes effective immediately
IMPORTANT If a vendor ID is configured for a specific client device, please REBOOT the client device attached to the modem to allow it to
obtain an appropriate IP address.
WAN Service
VPN
LAN
NAT
Security
Parental Control
Quality of Service
Routing
DNS
DSL
UPnp
DNS Proxy
Print Server
Layer 2 Interface
Advanced Setp
Interface Grouping
Group Name:
WAN Interface used in the grouping
Ipoe_0_0_34/atm1
Grouped LAN Interfaces
Available LAN Interfaces
Eth0
Eth1
Eth3
Eth4
>
>
