IP Sec Configuration Example Site B
Parameter
Setting
Options
IP Sec Connection Name
IPSecB
Free style name
Tunnel Mode
ESP
Select ESP or AH
Remote IP Sec Gateway Address
113.90.14.180
WAN IP address of site A
Site
A
Tunnel Access from local IP Address
Subnet
Subnet or single address
IP Address for VPN
192.168.2.0
LAN IP Range of Site B
IP Sub network mask – site A
255.255.255.0
Sub network mask for Site B
Site
B
Tunnel Access from remote IP Address
Subnet
Subnet or single address
IP Address for VPN
192.168.1.0
LAN IP Range of Site A
IP Sub network mask – site B
Sub network mask for Site A
Key Exchange Method
Auto(IKE)
Auto or Manual
Authentication method
Pre-shared Key
Pre-shared of certificate X509
Pre-shared Key (Maxlength:128)
Key
Perfect Forward Secrecy
Disable
Disable or enable
Advanced IKE Settings
Shows Advanced Settings
Save / Apply
Having saved / applied this configuration the Case Communications 6401 Router will return you to
the first IP sec page and display the Tunnel you have just configured, as shown below
Connection Name
Remote Gateway
Local Addresses
Remote Addresses
Remove
IPSecB
113.90.14.180
192.168.2.0
192.168.1.0
Add New Connections
Remove
