OPERATION & MAINTENANCE MANUAL STE35SR
Specifications
Item Unit Parameter
A Overall length mm 4200
B Grounding length (Transportation)
mm 2740
C Overall height(to the top of boom)
mm 1545
D Overall width mm 1550
E Overall height(to the top of cab) mm 2480
F Counterweight ground clearance
mm 575
G Min. Ground clearance mm 270
H Tail radius of turning mm 775
I Tumbler center distance mm 1540
J Length of track mm 2020
K Gauge mm 1250
L Track width mm 1550
M Track shoe width mm 300
N Turntable width mm 2300
O Item mm 1400
P Turntable width mm 490
RQ Right arm offset mm 610
LQ Left arm offset mm 565
RT Right offset angle of boom mm
55°
LT Left offset angle of boom mm
65°
