OPERATION & MAINTENANCE MANUAL STE35SR
Machine Operation: Move and Stop
Matters Need Attention of Moving the Machine
Before operating the control lever, check the direction of the track frame. If the sprocket is at
the front, the machine moves in the opposite direction from the operation of the travel lever.
Before starting the machine, check that the area around the machine is safe and sound the
speaker.
Do not allow anyone to enter the area around the machine.
Clear any obstacles from the travel path.
Here is a blind spot at the rear of the machine, so be particularly careful when traveling in
reverse.
Preparation before the machine moves
Pull the throttle lever back to increase the engine speed.
Moving Forward
1.Open the safety lock lever, put away the working
device and lift it 40-50cm from the ground.
2.Pull the blade control lever backward to raise the
blade.
3.Operate the walking joystick according to the following
steps.
When the driving wheel ○
A
is at the back of the
machine, slowly push the left and right walking
joysticks forward to move the machine.
When the driving wheel ○
A
is at the front of the
machine, slowly pull the left and right walking
joysticks back to move the machine.
4.Follow the steps below to switch the walking speed.
Press the walking speed switch to the high-end "rabbit gear" to switch from low-speed walking to
high-speed walking.
Press the walking speed switch to low gear to switch from high speed to low speed.
