OPERATION & MAINTENANCE MANUAL STE35SR
Recommended Applications
In addition to the following, it is possible to further increase the range of applications by using
various attachments.
Backhoe Work
A backhoe is suitable for excavating areas that are
lower than the machine.
When the condition of the machine is as shown in the
diagram on the right (angle between [bucket cylinder
and link] and [arm cylinder and arm] is 90°), the
maximum excavation force is obtained from the
pushing force of each cylinder.
When excavating, use this angle effectively to
optimize your working efficiency.
The range for excavating with the arm is from a 45°
angle away from the machine to a 30° angle towards
the machine.
There may be some differences depending on the
excavation depth, but try to stay within the above
range rather than operating the cylinder to the end of
its stroke.
Ditching
Ditching work can be performed efficiently by
attaching a bucket which matches the digging
operation and then setting the tracks parallel to the
line of the ditch to be excavated.
To excavate a wide ditch, first dig both sides and
then finally remove the center portion.
Loading Work
In places where the swing angle is narrow, work
efficiency can be enhanced by locating the dump
truck in a place easily visible to the operator.
Loading is easier and capacity greater if you begin
from the behind of the dump truck body than if
loading is done from the side.
Smoothing Operation
Use the plow to carry out the landfill and smooth
operation after excavation.
