OPERATION & MAINTENANCE MANUAL STE35SR
Working Ranges
Item Unit Parameter
A Max. Digging height mm 4390
B Max. Dumping height mm 3060
C Max. Digging depth mm 2800
D Max. Vertical Digging depth mm 2310
E Max. Digging reach mm 4800
F Max. Digging reached at ground level mm 4680
G Min. Swing radius of work equipment mm 775
H Max lifting height of the blade mm 300
I Max cutting depth of the blade mm 320
