OPERATION & MAINTENANCE MANUAL STE35SR
Securing Machine
IMPORTANT
To prevent damage to the bucket cylinder during
transportation, put a wooden block under the tip of
the bucket link to prevent the bucket cylinder from
touching the floor.
Load the machine onto a trailer as follows:
1. Lower the blade.
2. Extend the bucket and arm cylinders fully, then lower
the boom slowly.
3. Set the lock lever securely to the LOCK position (L).
4. Stop the engine, then remove the key from the starting switch.
5. Close all doors, windows, and covers. Lock the covers, caps, and doors fitted with locks.
IMPORTANT
Do not use the holes for fixed at the rear of the track frame for traction, also don't use it to lifting
machines and so on.
6. Place blocks under both ends of the tracks to prevent
the machine from moving during transportation, and
secure the machine with chains or wire rope of
suitable strength. Be particularly careful to secure the
machine in position so it does not slip to the side.
To Next Page
