OPERATION & MAINTENANCE MANUAL STE35SR
NOTICE
When performing inspection and maintenance inside the hood, the hood must be fully opened and
locked with struts.
1. Open the hood and lock it with a strut.
2. Remove dipstick (3), and wipe the oil off with a
clean cloth.
3. Fully insert dipstick (3) into filler pipe, then
remove it.
4. The oil level should be between the H and L
marks on dipstick (3). If the oil level is below the L
mark, add engine oil through oil filler (1).
5. If the oil is above the H line, open drain valve (P)
at the bottom of the engine oil pan, drain the excess
engine oil, then check the oil level again.
6. If oil level is correct, securely tighten the oil filler
cap and close the engine hood.
NOTICE
When checking the oil level after the engine has been operated, wait for at least 15 minutes
after stopping the engine before checking.
If the machine is Inclined, make it to a horizontal position before checking.
