5. Rover station setup and operation
i80 GNSS Receiver User Guide Page 46
an existing project → establish the connection with receiver via
Bluetooth or Wi-Fi (see 2.7. Connecting to a controller for the
operations).
3. After successful connection, tap Rover Config in the Device screen.
4. In Rover Config screen, configure the related parameters from the
dropdown list or enter the value with the soft keyboard: Data Format,
Elevation Mask, PDOP Limit, Safe Mode and Iono Condition.
Note – Select the Data Format the same as that of base receiver.
5. Configure the antenna parameters as follows:
Type field: tap next to Type field to select CHCi80 as antenna type.
Measure To field: select Bottom from the dropdown list.
Height field: enter the height (in meters) of the range pole you are
using.
6. If required, tick Warning when base changed option → tap in the
lower right corner to save the settings and go back to Device screen.
7. Tap Communication Mode → select Network for Mode field.
8. Configure the network parameters as follows:
Protocol field: select the protocol according to your need.
IP Addr field: enter the IP address and the Port with the soft keyboard,
or tap next to this field to select the predefined
service.
Source field: tap next to this field to get the source table list, and
To Next Page
