Program Sequence
Clear Program has two options: CLEAR PROG = YES / NO. The main function of Clear
Program is to clear all sequences in that program.
3. Press “ ” to confirm.
4. Press “ ” to return to Figure 4-1.
4.1.2 Setting Sequence
1. The default number of SEQUENCEs for each PROGRAM is 0. A maximum of 100
SEQUENCES can be added to a PROGRAM. The total number of SEQUENCES that
can be set by the 10 PROGRAMS is 1000.
2. Adding a new SEQUENCE:
a. In the PROGRAM page (Figure 4-3), if the PROGRAM has no SEQUENCE when
the cursor is at (5), pressing “
” will add a new SEQUENCE. The page will
skip to Figure 4-8.
b. When the cursor is at (7) in Figure 4-8, press “
” to add a new SEQUENCE.
The “
” function key is usually used as a cursor movement key; in
the above situations it is used for adding new SEQUENCEs.
3. Use the “
”, “ ” keys to move the cursor to the column to be set as shown in
Figure 4-8.
4. Use the numeric keys
- or the “Rotary” ( ) knob to set the value.
[ S E Q U E N C E ]
S E Q N O = 1 _
S E Q T Y P E = A U T O T I M E = 0
. 0 0 0 ( S )
V O L T A G E = 0 . 0 0 V
V S . R . = 1 . 0 0 0 ( V/ m s )
C U R R E N T = 0 . 0 0 0 A
I
S . R .
= I N F . ( A / m s ) ▲
▼
( 1 )
( 2 )
( 4 )
( 5 )
( 6 )
( 7 )
( 3 )
Figure 4-8
Each sequence has seven options: (1) SEQ NO., (2) SEQ. TYPE, (3) TIME, (4)
VOLTAGE, (5) V S.R., (6) CURRENT and (7) I S.R. which are described below.
5. Press “ ” to confirm.
6. Press “ ” to return to the Program PAGE (Figure 4-3).
