Chroma 62150H-600S - Current Slew Rate Setting

Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
3-16
3.3.2.4 CURRENT SLEW RATE SETTING
1. Use the “ ”, “ ” keys to move the cursor to the column to be set.
Figure 3-22
2. Use the numeric keys (
0
- ) or the “Rotary” ( ) knob to set the value.
The output current slew rate of the DC Power Supply is set as shown in Figure 3-23. The
maximum input Slew Rate is 0.1A/mS and the minimum is 0.003A/mS. If the input is
larger than 0.3A/mS, the current Slew Rate will be set to INF. and will change with the
maximum slew rate (near infinite). The output of the DC Power Supply will follow the
rising slew rate to the set output current.
ΔT
ΔI
I
SR
T
∆
=
∆
Time(mS)
Io
Figure 3-23
3. Press “ ” to confirm.
4. Press “
EXIT
” to return to the MAIN PAGE.
9
ENTER
