Chroma 62150H-600S - Function Keys; Front Panel

Programmable DC Power Supply (with Solar Array Simulation) 62000H Series
Operating & Programming Manual
1-10
62050H-600S
±1200
62100H-600S
±1200
62150H-600S
±1200
62150H-1000S
±1200
A620028
±1200
A620027
±1200
If the voltage exceeds the above range it may result in damage to the DC
Power Supply.
1.4 Function Keys
1.4.1 Front Panel
Figure 1-3 Front Panel of 62000H with Solar Array Simulation
Figure 1-4 Front Panel of Slave Model A620027/A620028
