Cincinnati 400FM - Introduction; Identification

FM HYDRAULIC PRESS BRAKE
EM-446 (N-08/99)
1-1
SECTION 1 IDENTIFICATION
1. LEFT CYLINDER
2. LEFT HOUSING
3. CYLINDER MANIFOLD AND
VALVES (2)
4. COUNTERBALANCE MANIFOLD
AND VALVES (2)
5. RAM
6. RIGHT CYLINDER
7. RIGHT HOUSING
8. CAPACITY PLATE
9. FM CONTROL STATION
10. PALMBUTTON OPERATOR STATION
11. FOOTSWITCH
12. BED SHOE (2)
13. DIE CLAMPS
14. BED
15. LINEAR TRANSDUCER
FIGURE 1-1 – Front View
1
2 3 4 5 4 3 6 7
8
9
10
1112131412
15
