The “Calib” softkey is used to calibrate the back-
gage. This is only required when servicing the
backgage.
The “Zero XDCR” softkey is used to set the zero
point for the pressure transducer. This must be
done whenever the transducer, analog board or
CPU board is replaced. Make sure the main drive is
OFF before this softkey’s button is pressed.
The “Cycle Start” softkey will allow the machine to
be cycled. Exiting the DIAGNOSTICS screen will
break out of Cycle Active.
This concludes the PROGRAMMING and
OPERATION information for the Multi-
Axis Control.
❦
