CipherLab 8000 User Manual

107
Chapter 7 Utilities
Run AG_Load.exe
1. In the File Type box, select the file type of the target AG template file.
File Type Description
The AGX format is used by the template file of Forge Batch AG
program for 8000/8200/8300/8400/8500/8600/8700 Series Mobile
Computers.
The ATX format is used by the template file of Batch AG program
AG711*.exe for 711 Mobile Computer.
The ATF format is used by the template file of WLAN AG programs for
8000/8200/8300/8400/8500/8600/8700 Series Mobile computers.
2. In the File name box, type the file path where the AG template file is located.
Otherwise, click Browse to locate the AG template file you want to download. Click Open in
the dialog box as shown below.

CipherLab 8000 Specifications

General

Operating System	Proprietary
Humidity	5% to 95% non-condensing
Barcode Scanner	Laser
Connectivity	RS-232
Ports	RS-232
Weight (Extended)	280g (with battery)
Storage Temperature	-20°C to 60°C
Drop Specification	1.2m
