The tables below list reader settings as well as symbology settings for the Long Range
Laser (LR) or Extra Long Range Laser (ELR) scan engine.
READER SETTINGS TABLE
LR/ELR Engine Description Default
Scan Mode Laser mode
Continuous Mode Non-stop scanning
To decode the same barcode repeatedly, move away the scan beam
and target it at the barcode for each scanning.
Test Mode Non-stop scanning
Capable of decoding the same barcode repeatedly
Alternate Mode Press the scan trigger to start with scanning.
The scanning won't stop until you press the trigger again.
Aiming Mode Press the scan trigger to aim at a barcode. Within one second, press the
trigger again to decode the barcode.
The scanning won't stop until (a) a barcode is decoded, (b) the pre-set
timeout expires, or (c) you release the trigger.
Laser Mode Hold down the scan trigger to start with scanning.
The scanning won't stop until (a) a barcode is read, (b) the preset
timeout expires, or (c) you release the trigger.
Auto Off Mode Press the scan trigger to start with scanning.
The scanning won't stop until (a) a barcode is read or (b) the preset
timeout expires.
Time-out 3 sec.
0~255 (second) Set the maximum time for decoding to continue during a scan attempt.
It applies to the following scan modes only –
Aiming mode
Laser mode
Auto Off mode
Aiming Duration 3 sec.
1~255 (second) Set the maximum time for decoding to continue during a scan attempt.
It applies to Aiming mode only.
Note: Scan Mode options and Aiming Duration are supported on Long Range Laser scan
engine for 8300/8700.
Appendix III
LR/ELR LASER SCAN ENGINE
