CipherLab 8000 User Manual

46
FORGE Batch Application Generator User Guide
1.9.2 TEXT
When “Text” is set to the data type of an input field, the input field accepts any ASCII
character. For example, $1a2b3c=-*/…
1.9.3 INTEGER
When “Integer” is set to the data type of an input field, the input field accepts the whole
numbers such as … -2, -1, 0, 1, 2 … but not 3.5.
1.9.4 REAL
When “Real” is set to the data type of an input field, the input field accepts any number
that features a decimal whether it is rational or irrational. For example, 4.56.
The following contents of this section will describe how a data collecting form interacts
with the specified lookup file when either “Real” or “Integer” is selected as the “Data
Type” for an input field.

CipherLab 8000 Specifications

General

Operating System	Proprietary
Humidity	5% to 95% non-condensing
Barcode Scanner	Laser
Connectivity	RS-232
Ports	RS-232
Weight (Extended)	280g (with battery)
Storage Temperature	-20°C to 60°C
Drop Specification	1.2m
