CipherLab 8000 User Manual

151
Appendix IV 2D Scan Engine
SYMBOLOGY SETTINGS TABLE
1D SYMBOLOGIES
2D Engine Description Default
Codabar Enable
Transmit Start/Stop
Character
Decide whether to include the start/stop characters in the
data being transmitted.
No
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
Any Length
Code 128 Enable
GS1-128 Enable
Replace Field
Separator
Decide whether to replace the field separator. If the
barcode contains Field Separator “0x1D”, it will be
changed to the desired Field Separator. For example, type
the desired character “;” (semicolon) as the new field
separator. Then if the barcode contains Field Separator
“0x1D”, it will be changed to “;”.
No
ISBT 128 Enable
Industrial 25 (Discrete 25) Enable
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
Any Length
Interleaved 25 Enable
Convert to EAN-13 Convert a 14-character barcode into EAN-13 if the
following requirements are met:
 The barcode must have a leading 0 and a valid EAN-13
check digit.
No
Verify Check Digit Decide whether to verify the check digit. If desired, select
one of the algorithms below. If the check digit is incorrect,
the barcode will not be accepted.
 No
 USS algorithm
 OPCC algorithm
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
No
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
Any Length

CipherLab 8000 Specifications

General

Operating System	Proprietary
Humidity	5% to 95% non-condensing
Barcode Scanner	Laser
Connectivity	RS-232
Ports	RS-232
Weight (Extended)	280g (with battery)
Storage Temperature	-20°C to 60°C
Drop Specification	1.2m
