The tables below list reader settings as well as symbology settings for the 2D scan
engine.
READER SETTINGS TABLE
2D Engine Description Default
Scan Mode Laser mode
Continuous Mode Non-stop scanning
 To decode the same barcode repeatedly, move away the scan beam
and target it at the barcode for each scanning.
Test Mode Non-stop scanning
 Capable of decoding the same barcode repeatedly
Alternate Mode Press the scan trigger to start with scanning.
 The scanning won't stop until you press the trigger again.
Aiming Mode Press the scan trigger to aim at a barcode. Within one second, press the
trigger again to decode the barcode.
 The scanning won't stop until (a) a barcode is decoded, (b) the pre-set
timeout expires, or (c) you release the trigger.
Laser Mode Hold down the scan trigger to start with scanning.
 The scanning won't stop until (a) a barcode is read, (b) the preset
timeout expires, or (c) you release the trigger.
Auto Off Mode Press the scan trigger to start with scanning.
 The scanning won't stop until (a) a barcode is read or (b) the preset
timeout expires.
Decode Illumination Decide whether to flash illumination on every barcode
capture to aid decoding.
 Turn On (Internal LED)
 Turn Off
On
Aiming Pattern Decide whether to project the aiming pattern during
barcode capture.
 Turn On
 Turn Off
On
