133
Appendix II
CCD/Laser Scan Engine
SYMBOLOGY SETTINGS TABLE
CCD/Laser Engine Description Default
Codabar Enable
Transmit Start/Stop
Character
Decide whether to include the start/stop characters in the
data being transmitted.
If "Transmit Start/Stop Characters" is desired, select one
set:
abcd / abcd
abcd / tn*e
ABCD / ABCD
ABCD / TN*E
No
Code 128 Enable
GS1-128 Enable
Transmit Code ID (for
GS1-128)
Decide whether to include Code ID (“]C1”) will be included
in the data being transmitted.
No
Replace Field
Separator
Decide whether to replace the field separator. If the
barcode contains Field Separator “0x1D”, it will be
changed to the desired Field Separator. For example, type
the desired character “;” (semicolon) as the new field
separator. Then if the barcode contains Field Separator
“0x1D”, it will be changed to “;”.
No
ISBT 128 Enable
Industrial 25 (Discrete 25) Enable
Start/Stop Selection This decides the readability of all 2 of 5 symbology
variants. For example, flight tickets actually use an
Industrial 2 of 5 barcode but with Interleaved 2 of 5
start/stop pattern. In order to read this barcode, the
start/stop pattern selection parameter of Industrial 2 of 5
should set to "Interleaved 25".
Industrial 25
Verify Check Digit Decide whether to verify the check digit. If the check digit
is incorrect, the barcode will not be accepted.
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
Select Length
One or two fixed lengths
Range
1~127
Interleaved 25 Enable
Start/Stop Selection Refer to Industrial 25. Interleaved
25
Verify Check Digit Decide whether to verify the check digit. If the check digit
is incorrect, the barcode will not be accepted.
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
To Next Page
