CipherLab 8000 User Manual

134
FORGE Batch Application Generator User Guide
Select Length
 One or two fixed lengths
 Range
1~127
Matrix 25 Disable
Start/Stop Selection Refer to Industrial 25. Matrix 25
Verify Check Digit Decide whether to verify the check digit. If the check digit
is incorrect, the barcode will not be accepted.
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
Select Length
 One or two fixed lengths
 Range
1~127
Coop 25 Disable
Verify Check Digit Decide whether to verify the check digit. If the check digit
is incorrect, the barcode will not be accepted.
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
Note: Coop 25 is supported on CCD/Laser scan engine for
8000/8200/8300/8400/8600/8700 only.
French Pharmacode Disable
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
Italian Pharmacode (Code 32) Disable
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
Note: For French/Italian Pharmacode, “Transmit Start/Stop Character” is not provided in
UI but it is controlled by the same setting of Code 39.
Code 39 Enable
Transmit Start/Stop
Character
Decide whether to include the start/stop characters "*" in
the data being transmitted.
No
Verify Check Digit Decide whether to verify the check digit. If the check digit
is incorrect, the barcode will not be accepted.
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
Code 39 Full ASCII Code 39 Full ASCII includes all the alphanumeric and
special characters.
No
Security Level
 High
 Normal
High
Code 93 Enable
