CipherLab 8000 User Manual

141
Appendix III LR/ELR Laser Scan Engine
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
 "Verify Check Digit" must be enabled so that the check
digit can be left out (= "Transmit Check Digit"
disabled).
No
Code 39 Full ASCII Code 39 Full ASCII includes all the alphanumeric and
special characters.
Disable
Trioptic Code 39 Decide whether to decode Trioptic Code 39.
 Trioptic Code 39 is a variant of Code 39 used in the
marking of computer tape cartridges. It always
contains six characters.
Disable
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
Any Length
Code 93 Enable
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
Any Length
MSI Enable
Verify Check Digit If Two Check Digits option is selected, an additional
verification is required to ensure integrity. Select one of
the algorithms below. If the check digit is incorrect, the
barcode will not be accepted.
Check Digit Algorithm
One Check Digit Single Modulo 10
Two Check Digits
 Mod 10/Mod 11
 Mod 10/Mod 10
Single Modulo
10
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
No
Select Length
 Any Length
 One or two fixed lengths
 Range (1~55)
Any Length
GS1 Databar ---
GS1 Databar-14 GS1 DataBar-14 is short for GS1 DataBar Omnidirectional.
This group consists of (1) GS1 DataBar Omnidirectional,
(2) GS1 DataBar Truncated, (3) GS1 DataBar Stacked, and
(4) GS1 DataBar Stacked Omnidirectional.
Enable
GS1 Databar Limited Enable
GS1 Databar Expanded This group consists of (1) GS1 DataBar Expanded, and (2)
GS1 DataBar Expanded Stacked.
Enable

CipherLab 8000 Specifications

General

Operating System	Proprietary
Humidity	5% to 95% non-condensing
Barcode Scanner	Laser
Connectivity	RS-232
Ports	RS-232
Weight (Extended)	280g (with battery)
Storage Temperature	-20°C to 60°C
Drop Specification	1.2m
