FORGE Batch Application Generator User Guide
UPC Composite Mode UPC barcodes can be "linked" with a 2D barcode during
transmission as if they were one barcode.
UPC Never Linked
Transmit UPC barcodes regardless of whether a 2D
barcode is detected.
UPC Always
Linked
UPC Always Linked
Transmit UPC barcodes and the 2D portion. If the 2D
portion is not detected, the UPC barcode will not be
transmitted.
 CC-A/B or CC-C must be enabled!
Auto-discriminate UPC Composites
Transmit UPC barcodes as well as the 2D portion if
present.
GS1 Formatting ---
GS1-128 (EAN128) Decide whether to enable GS1 formatting for GS1-128. Disable
GS1 DataBar
Omnidirectional
Decide whether to enable GS1 formatting for GS1 DataBar
Omnidirectional.
Disable
GS1 DataBar Limited Decide whether to enable GS1 formatting for GS1 DataBar
Limited.
Disable
GS1 DataBar Expanded Decide whether to enable GS1 formatting for GS1 DataBar
Expanded.
Disable
Composite CC- A/B Decide whether to enable GS1 formatting for Composite
CC-A/B.
Disable
Composite CC-C Decide whether to enable GS1 formatting for Composite
CC-C.
Disable
Field Separator Specify the field separator. No
Application ID Mark Specify the application ID mark character. No

CipherLab 8000 Specifications

General

Operating System	Proprietary
Humidity	5% to 95% non-condensing
Barcode Scanner	Laser
Connectivity	RS-232
Ports	RS-232
Weight (Extended)	280g (with battery)
Storage Temperature	-20°C to 60°C
Drop Specification	1.2m
