CipherLab 8000 User Manual

158
FORGE Batch Application Generator User Guide
MicroQR Enable
Aztec Enable
Aztec Inverse Decide whether to decode Aztec Inverse.
Regular Only
Decode regular Aztec barcodes only.
Inverse Only
Decode inverse Aztec barcodes only.
Inverse Autodetect
Decode both regular and inverse Aztec barcodes.
Regular Only
Note: Data Matrix Mirror, MicroQR, Aztec, and 2D Inverse are supported on 2D scan
engine for 8200/8400/8600/8700 only.
2D Symbologies - Macro PDF ---
Macro PDF is a special feature for concatenating multiple PDF barcodes into one file, known as
Macro PDF417 or Macro MicroPDF417.
Transmit/Decode Mode Decide how to handle Macro PDF decoding.
Buffer All Symbols / Transmit Macro PDF When Complete
Transmit all decoded data from an entire Macro PDF
sequence only when the entire sequence is scanned and
decoded. If the decoded data exceeds the limit of 50
symbols, no transmission because the entire sequence
was not scanned!
Transmit Any Symbol in Set / No Particular Order
Transmit data from each Macro PDF symbol as decoded,
regardless of the sequence.
Passthrough
All Symbols
Passthrough All Symbols
Transmit and decode all Macro PDF symbols and
perform no processing. In this mode, the host is
responsible for detecting and parsing the Macro PDF
sequences.
ESC Characters When enabled, it uses the backslash "\" as an Escape
character for systems that can process transmissions
containing special data sequences. It will format special
data according to the Global Label Identifier (GLI)
protocol, which only affects the data portion of a Macro
PDF symbol transmission. The Control Header, if enabled,
is always sent with GLI formatting.
None
