CipherLab 9700 Reference Manual

183
Chapte
r
5 More Applications
MANAGING MEMBER LIST
The Member List will show all other devices (not including the device under operation) that
have connected to the wireless subnet and are currently running the Push to Talk
application.
OPEN MEMBER LIST
1) Launch Push to Talk as described in Launch Push to Talk.
2) Tap Member List on the Push to Talk menu bar to view all members in the current
group.
The number of devices connected to the group will be shown on the Member List label.
Tap Member List again to close the list.
CHECK MEMBER STATUS
In the Member List, a short bar in front of the device name will change its color to indicate
the status of that device. Possible colors are:
Status
Mode Meaning
Green Voice reception mode Device is connected to the wireless subnet and is currently
running Push to Talk.
Red Active transmit mode Device is transmitting audio message to other devices.
Yellow Passive transmit mode Device is receiving audio message from another device.
Gray Disconnected Device has been disconnected from the group. Make sure
device has Wi-Fi access, the system hasn’t shut down or
entered suspension, and is still running the Push to Talk
application.
Shows all other devices in the current group
T
ap to open Member List

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
