CipherLab 9700 Reference Manual

194
9700 Mobile Computer (CE) Reference Manual
Digit
Pair
Hardware Code
1
st
Barcode
Reader
0: None:
1: Laser
2: Laser
3: 2D imager
4: Long range laser
5: 2D imager
7: Extra long range 2D
imager
9: Extra long range laser
2
nd
-- N/A
3
rd
Bluetooth 0: None
1: Bluetooth
4
th
Wi-Fi 0: None
1: Wi-Fi
5
th
-- N/A
6
th
Keypad 0: None
3: Numeric (30-key)
4: Numeric & Function
(38-key)
5: Alphanumeric
(53-key)
6: Alphanumeric
(53-key)
7: Alphanumeric
(53-key)
7
th
LCD 0: None
3: QVGA
8
th
-- N/A
9
th
-- N/A
10
th
Touch panel 0: None
1: 3.5” QVGA
Transflective
11
th
-- N/A
TERMINAL SERVER CLIENT
Logs onto a Windows Terminal Server or a remote computer through remote desktop
connection. You may then access all programs, files and network resources on the
remote host or terminal server.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
