CipherLab 9700 Reference Manual

215
Appendix II Lase
r
(SE955)
UPC-A
UPC-A Checkbox to enable UPC-A decoding. Enable
Preamble Decide whether to include the UPC-A/UPC-E/UPC-E1
preamble System Character (and Country Code) in the data
being transmitted.
 No transmit: transmits none of the above
 Transmit System Character: transmits system number
only
 Transmit Sys. Character and Country Code: transmits
system number and country code
Transmit
System
Character
Transmit Check Digit Decide whether to include the UPC-A check digit (the last
character in the barcode) in the data being transmitted.
Enable
UPC-E
UPC-E Checkbox to enable UPC-E decoding. Enable
Preamble Decide whether to include the UPC-A/UPC-E/UPC-E1
preamble System Character (and Country Code) in the data
being transmitted.
 No transmit: transmits none of the above
 Transmit System Character: transmits system number
only
 Transmit Sys. Character and Country Code: transmits
system number and country code
Transmit
System
Character
Convert to UPC-A The UPC-E barcode will be expanded into UPC-A format, and
the next process will follow the settings configured for
UPC-A.
Disable
Transmit Check Digit Decide whether to include the UPC-E1 check digit (the last
character in the barcode) in the data being transmitted.
Enable
UPC-E1
UPC-E1 Checkbox to enable UPC-E1 decoding. Disable
Preamble Decide whether to include the UPC-A/UPC-E/UPC-E1
preamble System Character (and Country Code) in the data
being transmitted.
 No transmit: transmits none of the above
 Transmit System Character: transmits system number
only
 Transmit Sys. Character and Country Code: transmits
system number and country code
Transmit
System
Character
Convert to UPC-A The UPC-E1 barcode will be expanded into UPC-A format,
and the next process will follow the settings configured for
UPC-A.
Disable
Transmit Check Digit Decide whether to include the UPC-E1 check digit (the last
character in the barcode) in the data being transmitted.
Enable
General Preference
Support Coupon Code Reads UPC-A barcodes starting with “5”, EAN-13 barcodes
starting with “99”, and UPC-A/EAN-128 Coupon Codes.
 UPC-A, EAN-13, and GS1-128 must be enabled first!
 Use “Addon Redundancy” to control auto-discrimination
of the GS1-128 (right half) of a coupon code.
Disable

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
