CipherLab 9700 Reference Manual

214
9700 Mobile Computer (CE) Reference Manual
Convert to UPC/EAN This only applies to GS1 DataBar-14 and GS1 DataBar
Limited barcodes not decoded as part of a Composite
barcode.
Convert to EAN-13
Strips the leading “010” from barcodes.
 The barcode must be composed of a leading “01” as
the application identifier (AI) and a first digit of zero.
Convert to UPC-A
Strips the leading “0100” from barcodes.
 The barcode must be composed of a leading “01” as
the application identifier (AI) and two or more zeros
(but not six zeros).
Disable
MSI
MSI
MSI Checkbox to enable MSI decoding. Enable
Length option Sets the length of the MSI symbols to decode.
 One Fixed length (Length 1)
 Two Fixed lengths (Length 1>Length 2)
 Max / Min Length (range: 0-55; Length 1<Length 2)
 Any Length
Max / Min
Length
(4-55)
Check Digit Option One check digit is mandatory for decoding MSI barcodes.
Select whether a second check digit should be verified. If the
check digits are incorrect, the barcode will not be accepted.
 One Check Digit
 Two Check Digits
One Check
Digit
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Disable
Algorithm When two check digits are set for verification, two choices
are available for the pair of check digits.
 Modulo10 / Modulo11
 Double Modulo 10
Double
Modulo 10
UPC/EAN
EAN-8
EAN-8 Checkbox to enable EAN-8 decoding. Enable
EAN-8 Extend Checkbox to enable converting EAN-8 to EAN-13 format. Disable
EAN-13
EAN-13 Checkbox to enable EAN-13 decoding. Enable
Bookland EAN Checkbox to enable ISBN decoding. If enabled, select
Bookland ISBN Format in the drop-down box below.
Enable
Bookland ISBN Format Select to decode Bookland data starting with 978 as 10-digit
format along with the Bookland check digit, or decode
Bookland data starting with 978/979 as EAN-13 format.
Bookland
ISBN-10
Transmit Check Digit Decide whether to include the EAN-13 check digit (the last
character in the barcode) in the data being transmitted.
Enable

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
