9700 Mobile Computer (CE) Reference Manual
0 Modulo 10 check digit verified and transmitted. MSI
1 Modulo 10 check digit verified but not transmitted.
Industrial 25
(Discrete 25)
0 Always transmit 0.
0 Standard data packet in full EAN country code format, which
is 13 digits for UPC-A and UPC-E (not including addons).
3 Standard data packet with two-digit or five-digit addons.
4 EAN-8 data packet.
UPC/EAN
A UPC-A with Addon 2 barcode, 012345678905-10, is transmitted to the host
as a 18-character string, ]E3001234567890510.
Bookland EAN 0 Always transmit 0.
Trioptic Code 39 0 Always transmit 0.
0 Single check digit (has been verified.)
1 Two check digits (has been verified.)
Code 11
3 Check digit has been verified but not transmitted.
0 Always transmit 0. GS1 DataBar (RSS)
RSS-14 and RSS Limited will be transmitted with an Application Identifier “01”.
For example, an RSS-14 barcode, 10012345678902, is transmitted
as ]e00110012345678902.
Note: In EAN-128 emulation mode, RSS is transmitted using Code 128 rules (= “]C1”).
Native mode transmission
0 Standard data packet
1 Data packet containing the data following an encoded symbol
separator character.
2 Data packet containing the data following an escape
mechanism character. The data packet does not support the
ECI protocol.
3 Data packet containing the data following an escape
mechanism character. The data packet supports the ECI
protocol.
EAN-128 emulation
EAN.UCC
Composites (RSS,
EAN-128, 2D
portion of UPC
composite)
1 Data packet is a EAN-128 barcode (= data is preceded with
“]JC1”).
Note: UPC portion of composite is transmitted using UPC rules.
0 Scan engine is set to conform to protocol defined in 1994
PDF417 symbology specifications.
 When this option is transmitted, the receiver cannot
reliably determine whether ECIs have been invoked or
whether data byte 92
DEC
has been doubled in
transmission.
PDF417,
Micro PDF417
1 Scan engine is set to follow the ECI protocol (Extended
Channel Interpretation). All data characters 92
DEC
are
doubled.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
