CipherLab 9700 Reference Manual

219
Appendix II Lase
r
(SE955)
2 Scan engine is set for Basic Channel operation (no escape
character transmission protocol). Data characters 92
DEC
are
not doubled.
 When decoders are set to this mode, unbuffered Macro
symbols and symbols requiring the decoder to convey ECI
escape sequences cannot be transmitted.
3 The barcode contains a EAN-128 symbol, and the first
codeword is 903-907, 912, 914, 915.
4 The barcode contains a EAN-128 symbol, and the first
codeword is in the range 908-909.
5 The barcode contains a EAN-128 symbol, and the first
codeword is in the range 910-911.
A PDF417 barcode, ABCD, with no transmission protocol enabled, is
transmitted as ]L2ABCD.
0 ECC 000-140, not supported.
1 ECC 200.
2
ECC 200, FNC1 in first or fifth position.
3
ECC 200, FNC1 in second or sixth position.
4 ECC 200, ECI protocol implemented.
5
ECC 200, FNC1 in first or fifth position, ECI protocol
implemented.
Data Matrix
6
ECC 200, FNC1 in second or sixth position, ECI protocol
implemented.
0 Mode 4 or 5
1 Mode 2 or 3
2 Mode 4 or 5, ECI protocol implemented.
Maxicode
3 Mode 2 or 3, ECI protocol implemented in secondary
message.
0 Model 1
1 Model 2 / MicroQR ECI protocol not implemented.
2 Model 2, ECI protocol implemented.
3
Model 2, ECI protocol not implemented, FNC1 implied in first
position.
4
Model 2, ECI protocol implemented, FNC1 implied in first
position.
5
Model 2, ECI protocol not implemented, FNC1 implied in
second position.
QR Code
6
Model 2, ECI protocol implemented, FNC1 implied in second
position
0 Aztec symbol. Aztec
C Aztec Rune symbol.
Note: For JPEG files, these BPP settings are ignored for it always uses 8 bits per pixel!

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
