CipherLab 9700 Reference Manual

223
Appendix III Lase
r
(SE1524)
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Disable
Convert To EAN-13 Convert a 14-character Interleaved 25 barcode into EAN-13
if the following requirements are met:
The barcode must have a leading 0 and a valid EAN-13 check
digit.
Disable
GS1 DATABAR
GS1 DataBar-14
Enable GS1 DataBar-14 Checkbox to enable GS1 DataBar-14 decoding. Enable
GS1 DataBar Limited
Enable GS1 DataBar
Limited
Checkbox to enable GS1 DataBar Limited decoding. Enable
GS1 DataBar Expanded
Enable GS1 DataBar
Expanded
Checkbox to enable GS1 DataBar Expanded decoding. Enable
Convert to UPC/EAN
Convert to UPC/EAN This only applies to GS1 DataBar-14 and GS1 DataBar
Limited barcodes not decoded as part of a Composite
barcode.
Convert to EAN-13
Strips the leading “010” from barcodes.
 The barcode must be composed of a leading “01” as
the application identifier (AI) and a first digit of zero.
Convert to UPC-A
Strips the leading “0100” from barcodes.
 The barcode must be composed of a leading “01” as
the application identifier (AI) and two or more zeros
(but not six zeros).
Disable
MSI
MSI
MSI Checkbox to enable MSI decoding. Enable
Length option Sets the length of the MSI symbols to decode.
 One Fixed length (Length 1)
 Two Fixed lengths (Length 1>Length 2)
 Max / Min Length (range: 0-55; Length 1<Length 2)
 Any Length
Max / Min
Length
(4-55)
Check Digit Option One check digit is mandatory for decoding MSI barcodes.
Select whether a second check digit should be verified. If the
check digits are incorrect, the barcode will not be accepted.
 One Check Digit
 Two Check Digits
One Check
Digit
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Disable

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
