CipherLab 9700 Reference Manual

240
9700 Mobile Computer (CE) Reference Manual
UPC Composite Mode UPC barcodes can be "linked" with a 2D barcode during
transmission as if they were one barcode.
UPC Never Linked
Transmit UPC barcodes regardless of whether a 2D
barcode is detected.
UPC Always Linked
Transmit UPC barcodes and the 2D portion. If the 2D
portion is not detected, the UPC barcode will not be
transmitted.
 CC-A/B or CC-C must be enabled.
Auto-discriminate
Transmit UPC barcodes as well as the 2D portion if
present.
UPC Always
Linked
GS1-128 Emulation
Mode
Sets GS1-128 emulation mode for UCC/EAN Composite
Codes.
Disable
GS1 DATABAR
GS1 DataBar-14
Enable GS1 DataBar-14 Checkbox to enable GS1 DataBar-14 decoding. Enable
GS1 DataBar Limited
Enable GS1
DataBar-Limited
Checkbox to enable GS1 DataBar-Limited decoding. Enable
GS1 DataBar Expanded
Enable GS1
DataBar-Expanded
Checkbox to enable GS1 DataBar-Expanded decoding. Enable
INVERSE
Inverse
Enable Inverse Checkbox to enable Inverse 1D decoding. Disable
MSI
MSI
MSI Checkbox to enable MSI decoding. Enable
Length option Sets the length of the MSI symbols to decode.
 One Fixed length (Length 1)
 Two Fixed lengths (Length 1>Length 2)
 Max / Min Length (range: 0-55; Length 1<Length 2)
 Any Length
Max / Min
Length
(4-55)
Check Digit Option One check digit is mandatory for decoding MSI barcodes.
Select whether a second check digit should be verified. If the
check digits are incorrect, the barcode will not be accepted.
 One Check Digit
 Two Check Digits
One Check
Digit
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Disable

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
