CipherLab 9700 Reference Manual

241
Appendix V 2D Image
r
(EX25)
Algorithm
When two check digits are set for verification, two choices
are available for the pair of check digits.
 Modulo10 / Modulo11
 Double Modulo 10
Double
Modulo 10
POSTAL CODE
Australian Postal
Enable Australian
Postal
Checkbox to enable Australian Postal decoding. Enable
Japan Postal
Enable Japan Postal Checkbox to enable Japan Postal decoding. Enable
Netherlands KIX Code
Enable Netherlands KIX
Code
Checkbox to enable Netherlands KIX Code decoding. Enable
US Postnet
Enable US Postnet Checkbox to enable US Postnet decoding. Enable
US Planet
Enable US Planet Checkbox to enable US Planet decoding. Enable
General Preference
US Postal Check Digit Decide whether to transmit check digit for US Postnet or US
Planet.
Enable
UPC/EAN
EAN-8
EAN-8 Checkbox to enable EAN-8 decoding. Enable
EAN-13
EAN-13 Checkbox to enable EAN-13 decoding. Enable
Transmit Check Digit Decide whether to include the EAN-13 check digit (the last
character in the barcode) in the data being transmitted.
Enable
ISSN EAN Checkbox to enable ISSN EAN decoding. Disable
UPC-A
UPC-A Checkbox to enable UPC-A decoding. Enable
Preamble Decide whether to include the UPC-A/UPC-E/UPC-E1
preamble System Character (and Country Code) in the data
being transmitted.
 No transmit: transmits none of the above
 Transmit System Character: transmits system number
only
 Transmit Sys. Character and Country Code: transmits
system number and country code
Transmit
System
Character
Transmit Check Digit Decide whether to include the UPC-A check digit (the last
character in the barcode) in the data being transmitted.
Enable
UPC-E
UPC-E Checkbox to enable UPC-E decoding. Enable

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
