Cisco ASR 9000 Series System Configuration Guide

SUMMARY STEPS
1.
interface type interface-path-id
2.
ipv4 point-to-point
3.
ipv4 unnumbered interface-type interface-instance
4.
nv
5.
satellite-fabric-link network
6.
redundancy iccp-group group-number
7.
satellite satellite-id
8.
remote-portsinterface_type remote_subslot
9.
service-policy output parent-policy-map-name
10.
commit
11.
exit
DETAILED STEPS
PurposeCommand or Action
Configures an interface and enters the interface
configuration mode.
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface
GigabitEthernet0/2/0/1
Step 1
Configures the IPv4 point to point address.ipv4 point-to-point
Example:
RP/0/RSP0/CPU0:router(config-if)# ipv4 point-to-point
Step 2
Enables IPv4 processing on a point-to-point interface
without assigning an explicit IPv4 address to that
interface.
ipv4 unnumbered interface-type interface-instance
Example:
RP/0/RSP0/CPU0:router(config-if)# ipv4 unnumbered
Loopback10
Step 3
Enters the satellite network virtualization (nV)
configuration submode.
nv
Example:
RP/0/RSP0/CPU0:router(config-if)# nv
Step 4
Specifies the network type of Interface Control Plane
Extender(ICPE) inter-chassis link (ICL).
satellite-fabric-link network
Example:
RP/0/RSP0/CPU0:router(config-if-nV)#
satellite-fabric-link network
Step 5
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
98
Configuring QoS on the Satellite System
Attach Hierarchical Policies to the Interface
