Cisco ASR 9000 Series System Configuration Guide

PurposeCommand or Action
Ends the policy-map configuration.end-policy-map
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)#
end-policy-map
Step 5
configure
Step 6
Creates a parent policy map and enters the policy map
configuration mode.
policy-map parent-policy-map-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# policy-map
parent-policy
Step 7
Configures the parent class-default class.class class-default
Step 8
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class
class-default
Note
•
You can configure only the class-default class
in a parent policy. Do not configure any other
traffic class.
Shapes traffic to the indicated bit rate.
shape average rate [units]
Step 9
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# shape
average 1 mbps
In the parent policy, only the shape average action
is supported. For a 9000v satellite, the supported
minimum value is 40 mbps. For a 901 satellite, the
minimum value that is supported is 250 kbps.
Note
Applies a child-level policy to the top-level class-default
class.
service-policy child-policy-map-name
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)#
service-policy child-policy
Step 10
The service-policy command applies the
child-policy-map to the parent-policy-map.
Note
Ends the policy-map configuration.end-policy-map
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)#
end-policy-map
Step 11
Attach Hierarchical Policies to the Interface
This procedure attached the hierarchical policies to the interface.
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
97
Configuring QoS on the Satellite System
Attach Hierarchical Policies to the Interface
