You can specify the type of loopback to be used, as specified in this example:
Interface GigabitEthernet 100/0/0/0
loopback line | internal
Configuration Examples for Satellite nV System
This section contains these examples:
Satellite System Configuration: Example
This example shows a sample configuration for setting up the connectivity of a Satellite System.
Satellite Global Configuration
The satellite ID, type, serial number, description, and satellite IP address are configured in the satellite global
configuration submode:
nv
satellite 100
type asr9000v
serial-number CAT1521B1BB
description milpitas bldg20
ipv4 address 10.0.0.100
!
!
ICL (satellite-fabric-link) Interface Configuration
On the interface connected to the satellite (TenGig or Bundle interface), the ports associated with the satellite
ID must be specified. All fabric links connected to the same satellite must use the same (host) IPv4 address.
The same or different host IPv4 addresses can be used for the same host to connect to different satellites.
interface Loopback1000
vrf <vrf_name>
ipv4 address 10.0.0.1 255.0.0.0
vrf <vrf_name>
interface TenGigE0/2/1/0
description To Sat5 1/46
ipv4 point-to-point
ipv4 unnumbered Loopback1000
nv
satellite-fabric-link satellite 200
remote-ports GigabitEthernet 0/0/0-30
!
!
!
These examples illustrate using IP addresses from the global VRF of the router for satellite management
traffic. As discussed Satellite Discovery and Control Protocol IP Connectivity section, this can also be
done using a private VRF, to prevent IP address conflict with the global VRF. In this case, the loopback
interface and the ICL interfaces in the examples must be assigned to the private VRF dedicated for satellite
management traffic.
Note
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
65
Configuring the Satellite Network Virtualization (nV) System
Configuration Examples for Satellite nV System
