Cisco ASR 9000 Series System Configuration Guide

Satellite Interface Configuration
The Satellite interface can be used as any other regular Gigabit Ethernet interfaces:
interface GigabitEthernet200/0/0/0
l2transport
!
!
interface GigabitEthernet200/0/0/0
ip address 99.0.0.1 255.255.255.0
!
!
interface GigabitEthernet200/0/0/2
bundle id 100 mode active
!
!
This is a sample satellite interface configuration in the case of a dual home topology on
the active and standby hosts:
Active host:
interface GigabitEthernet100/0/0/32
ipv4 address 1.1.1.1 255.255.255.0
!
Active Host
interface GigabitEthernet100/0/0/32
ipv4 address 1.1.1.1 255.255.255.0
!
Standby Host
interface GigabitEthernet100/0/0/32
ipv4 address 1.1.1.1 255.255.255.0
!
For an L3 interface, the IPv4 protocol states in the output of show ipv4 interface brief command show as up;
up on the active host and up; down on the standby host.
Active host:
GigabitEthernet100/0/0/32 1.1.1.1 Up Up
Standby host:
GigabitEthernet100/0/0/32 1.1.1.1 Up Down
For an L2 interface, the ports show as up on both the hosts.
Active host:
GigabitEthernet100/0/0/33 unassigned Up Up
Standby host:
GigabitEthernet100/0/0/33 unassigned Up Up
You cannot add the satellite interface to the same bundle as the physical ICL link.Note
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
66
Configuring the Satellite Network Virtualization (nV) System
Satellite System Configuration: Example
