Cisco ASR 9000 Series System Configuration Guide

PurposeCommand or Action
Enters the satellite network virtualization (nV) configuration
submode.
nv
Example:
RP/0/RSP0/CPU0:router(config-if)# nv
Step 13
Attaches a policy map to an input interface to be used as
the service policy for that interface.
service-policy input policy-map
Example:
RP/0/RSP0/CPU0:router(config-if-nV)#
service-policy input policy2
Step 14
commit
Step 15
Returns the router to global configuration mode.exit
Example:
RP/0/RSP0/CPU0:router(config-if)# exit
Step 16
commit
Step 17
Offloading Service-policy on Physical Satellite Fabric Link
Perform these tasks to offload the service-policy on the physical Satellite Fabric Link (SFL). This procedure
offloads the service-policy in the egress direction of SFL.
SUMMARY STEPS
1.
configure
2.
class-map [type qos] [match-any] [match-all] class-map-name
3.
match qos-group [qos-group-value]
4.
end-class-map
5.
policy-map [ type qos ] policy-name
6.
class class-name
7.
bandwidth {bandwidth [units] | percent value}
8.
exit
9.
end-policy-map
10.
interface type interface-path-id
11.
nv
12.
satellite-fabric-link satellite satellite_id
13.
remote-ports interface_type remote_subslot
14.
service-policy output policy-map
15.
commit
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
83
Configuring QoS on the Satellite System
Offloading Service-policy on Physical Satellite Fabric Link
