Cisco ASR 9000 Series System Configuration Guide

Configuring the Thresholds for Optics Performance Monitoring
Parameters
Perform this task to configure the thresholds for Optics Performance Monitoring (PM) parameters.
SUMMARY STEPS
1.
configure
2.
controller optics R/S/I/P
3.
pm [15-min | 24-hour] optics [report | threshold] {lbc-pc | opr | opt} [max-tca | min-tca] enable
4.
pm [15-min | 24-hour] optics [report | threshold] {lbc -pc| opr | opt} [max | min] value
5.
commit
DETAILED STEPS
Step 1
configure
Step 2
controller optics R/S/I/P
Example:
RP/0/RSP0/CPU0:router (config)# controller optics 100/2/0/1
Enters the Optics controller configuration mode.
Step 3
pm [15-min | 24-hour] optics [report | threshold] {lbc-pc | opr | opt} [max-tca | min-tca] enable
Example:
RP/0/RSP0/CPU0:router (config-optics)# pm 15-min optics report lbc-pc max-tca enable
Specifies the PM interval for the optics controller and set report value for the LBC-PC layer. For the LBC-PC layer, only
the max-tca threshold can be specified, not min-tca (the minimum value).
Step 4
pm [15-min | 24-hour] optics [report | threshold] {lbc -pc| opr | opt} [max | min] value
Example:
RP/0/RSP0/CPU0:router (config-optics)# pm 15-min optics threshold opr max 15
Specifies the PM interval for the optics controller and set threshold value for the opr max.
Step 5
commit
Configuring the Thresholds for ODU Performance Monitoring
Parameters
Perform this task to configure the thresholds for ODU Performance Monitoring (PM) parameters.
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
127
Configuring the Performance Monitoring Thresholds for the Satellite nV Optical System
Configuring the Thresholds for Optics Performance Monitoring Parameters
