Cisco ASR 9000 Series System Configuration Guide

PurposeCommand or Action
Declares a new satellite optical shelf that is to be attached to the host
and enters the satellite configuration submode.
satellite satellite-id
Example:
RP/0/RSP0/CPU0:router(config-nV)#
satellite 100
Step 3
satellite-id is a number in the range of 100 to 65534.
Defines the expected type of the attached satellite. nV optical satellites
can have one of the following values:
type type-name
Example:
RP/0/RSP0/CPU0:router(config-satellite)#
type ons15454-m6
Step 4
•
ons15454-m6
•
ons15454-m2
•
ncs2002
•
ncs2006
Specifies the IP address (IPv4 or IPv6) used to connect to the satellite
along with an optional Virtual Route Forwarding (VRF) instance.
ip address { ipv4-address | ipv6-address }
Example:
RP/0/RSP0/CPU0:router(config-satellite)#
ip address 1.2.3.4
Step 5
Interface Control Plane Extender(ICPE) sets up a connected route to
the specified IP address through all configured inter-chassis links (ICLs).
(Optional) Specifies the name of the VRF that contains the IP address
used to connect to the satellite optical shelf.
(Optional) vrf vrf-name
Example:
RP/0/RSP0/CPU0:router(config-satellite)#
vrf mgmt
Step 6
Specifies the username and password to use to log into the interface
shelf. Enter the password in clear text or in hashed encrypted format.
At the time of display, the password appears in the encrypted format.
username string password { { 0|clear }
cleartext-password | { 5|encrypted }
encrypted-password | cleartext-password }
Example:
RP/0/RSP0/CPU0:router(config-satellite)#
username CISCO15 password otbu+1
Step 7
(Optional) Specifies the satellite string of the satellite. It is used to
ensure that the correct satellite is connected to by the host.
(Optional) serial string
Example:
RP/0/RSP0/CPU0:router(config-satellite)#
serial abcdrstv
Step 8
Saves configuration changes.end or commit
Step 9
Example:
RP/0/RSP0/CPU0:router(config)# end or
RP/0/RSP0/CPU0:router(config)# commit
•
When you issue the end command, the system prompts you to
commit changes:
Uncommitted changes found, commit them before
exiting(yes/no/cancel)?
[cancel]:
- Entering yes saves configuration changes to the running
configuration file, exits the configuration session, and returns the
router to EXEC mode.
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
116
Configuring the Satellite nV Optical Shelf System
Configuring the Satellite Optical Shelf Identity and Connection Parameters
