Cisco ASR 9000 Series System Configuration Guide

Default Profile:
SDRs:
Owner
Active Packages:
disk0:asr9k-fpd-px-5.1.0
disk0:asr9k-mgbl-px-5.1.0
disk0:asr9k-mpls-px-5.1.0
disk0:asr9k-mini-px-5.1.0
disk0:asr9k-bng-px-5.1.0
disk0:asr9k-px-5.1.0-CSCxxXXXXX-1.0.0
RP/0/RSP0/CPU0:ASR9006#show install committed summary
Default Profile:
SDRs:
Owner
Committed Packages:
disk0:asr9k-fpd-px-5.1.0
disk0:asr9k-mgbl-px-5.1.0
disk0:asr9k-mpls-px-5.1.0
disk0:asr9k-mini-px-5.1.0
disk0:asr9k-bng-px-5.1.0
disk0:asr9k-px-5.1.0-CSCxxXXXXX-1.0.0
2
Verify the data plane.
show nv edge data forwarding location all
<Snippet>
-----------------node0_RSP0_CPU0------------------
nV Edge Data interfaces in forwarding state: 4
TenGigE0_0_1_3 <--> TenGigE1_0_0_3
TenGigE0_1_1_3 <--> TenGigE1_1_0_3
TenGigE0_2_1_3 <--> TenGigE1_2_0_3
TenGigE0_3_1_3 <--> TenGigE1_3_0_3
<Snippet>
In this output, the IRLs must show in the forwarding state.
3
Verify the control plane.
show nv edge control control-link-protocols location 0/RSP0/CPU0
<Snippet>
Port enable administrative configuration setting: Enabled
Port enable operational state: Enabled
Current bidirectional state: Bidirectional
Current operational state: Advertisement - Single neighbor detected
Priority lPort Remote_lPort UDLD STP
======== ===== ============ ==== ========
0 0/RSP0/CPU0/0 1/RSP0/CPU0/0 UP Forwarding
1 0/RSP0/CPU0/1 1/RSP1/CPU0/1 UP Blocking
2 0/RSP1/CPU0/0 1/RSP1/CPU0/0 UP On Partner RSP
3 0/RSP1/CPU0/1 1/RSP0/CPU0/1 UP On Partner RSP
</Snippet>
From this output, the 'Current bidirectional state' must show as Bidirectional and only one of the ports
must be in the Forwarding state.
4
Verify the cluster status.
RP/0/RSP0/CPU0:ASR9006#admin show dsc
---------------------------------------------------------
Node ( Seq) Role Serial State
---------------------------------------------------------
0/RSP0/CPU0 ( 0) ACTIVE FOX1613G35U PRIMARY-DSC
0/RSP1/CPU0 (10610954) STANDBY FOX1613G35U NON-DSC
1/RSP0/CPU0 ( 453339) STANDBY FOX1611GQ5H NON-DSC
1/RSP1/CPU0 (10610865) ACTIVE FOX1611GQ5H BACKUP-DSC
This command displays both the DSC (inter rack) status and the redundancy role (intra rack) for all Route
Switch Processors (RSPs) in the system. In this example:
•
RSP0 on rack 0 is the primary-DSC and the active RSP for the rack.
Cisco ASR 9000 Series Aggregation Services Router nV System Configuration Guide, Release 5.3.x
152
Configuring the nV Edge System on the Cisco ASR 9000 Series Router
Verification
